CABLE SHARK AND WIRE SYSTEM

Ductmate's strongest, safest ever duct hanging sytem has incredible install flexibility. Two sizes of a powerful easy-to-use locking mechanism and wire spools to meet every type of job and weight requirement.
Seismic approved labour saving, versatile means for the suspension of static load HVAC systems indoors. Precision engineered to meet all SMACNA upper and lower construction standards.

• Ductmate Cable Shark Cable is designed for the suspension of HVAC systems. The Ductmate Cable Shark System and Ductmate Cable Shark Cable must always be used in conjunction.



  The new double-bore locking mechanism offers much greater flexibility and versatility for all types of duct hanging. The option of one mechanism and a ferrule loop can now also be used for increased cost-savings (see Information sheet below).



  Mechanisms and Wires come in two sizes to meet the requirements of every job. Max-load ratings of 125lbs (Wire Size: 2.5mm) and 250lbs (Wire Size: 4mm) with an incredible 10x Safety factor for your peace of mind.

  Note: The Cable Shark mechanisms or wire spools are not cross-compatible with Ductmate's former Clutcher and Wire System. Use of any other steel cable is prohibited.

• Meets SMACNA upper and lower attachment construction standards if used per manufacturer's installation guidelines
• Comprehensive Cable Shark Hanging System Load Charts and Installation Videos available online (see Spec Sheets below for Load Charts and the showcase page above for videos)
• Meets ICC-ES AC284 guidelines - Seismic Approved
• Engineered for strength and durability
• Fast and easy installation
• Compact design is aesthetically pleasing
• Available in 2 sizes to meet specific load ranges
• Versatile hanging options for nearly every application
• Engineered for superior strength
• Supplied in spools of 500′ and 1,000′ or cut to length
• Cable Shark 125 Cable is only compatible with the Cable Shark 125
• Cable Shark 250 Cable is only compatible with the Cable Shark 250
• Cable Shark Cable is available in pre-cut lengths

CABLE SHARK HANGING SYSTEM SPEC SHEET : DOWNLOAD

CABLE SHARK CONSTRUCTION STANDARDS: DOWNLOAD
